WR320 WiFi Music Box Manual

2020/06/03 ClassificationManual WiFi Audio WIFI Audio Adapter wifi-wireless-adapter 3686 0

2. Device connection method

1. Connect the WR320 to the charger with the attached USB charging cable. The WR320 will automatically power on and enter Wi-Fi mode. In Wi-Fi mode, the green indicator light is always on.

It is recommended to choose a regular charger with an output voltage of 5V 1A (do not use a variable voltage fast charging power supply).

Tips: In Wi-Fi mode, press the WPS button on the WR320, and then press the WPS button on the router, you can connect the WR320 to the Wi-Fi network without a driver. (If the router has no WPS button, please skip this step)

2. Turn on the mobile Wi-Fi and connect to the network.

3. Refer to the instructions for downloading APP software and connecting the device to the same local area network as the mobile phone.

4. Mode switching: you can switch between WIFI/Bluetooth/audio input by pressing the button M or APP, you can switch WIFI in the APP, and play on the music software in the APP will automatically switch to WIFI, and you can also use the protocol on the mobile music software Push to return to WIFI mode. Switching from Bluetooth mode to WIFI requires protocol push in another music software and cannot be switched by the same music software.

WR320 WiFi音乐盒说明书

3.Direct connection

You can directly connect your mobile phone/tablet to the Wi-Fi network of the music box WR320.

1. Turn on the Wi-Fi function of WR320.

2. Enter the Wi-Fi settings of the phone/tablet, and connect to the Wi-Fi network of WR320, the Wi-Fi name is “WR320***”

3. After the device is connected to the network, WR320 will become a router, which can play music or add another device.

Note: Press the Reset button for about 3 seconds to restore the factory settings of the Wi-Fi network.

4. Bluetooth connection

1. Press the “M” mode switch button to switch between Wi-Fi, Bluetooth, and Line-in modes.

2. WR320 will enter back-connection mode and automatically connect to any previously connected equipment. If there is no available device, the speaker will automatically enter the pairing mode after 4 seconds, and the LED light will flash blue.

3. Turn on the Bluetooth of your phone or tablet.

4. Search for Bluetooth devices, select WR320 and connect. Once the connection is successful, the blue LED light is always on.

5. When pairing with a new device, press and hold the play/pause button for 3 seconds to make the WR320 enter the Bluetooth pairing state again. This operation can be used in two situations, one is that a device has been connected to the WR320, and the other is that the WR320 is in the back-connection mode. In the pairing state, the LED light flashes blue.

Note: When your device is turned off, WR320 will enter the reconnect mode. The LED light flashes blue and connects to any previously connected device within the connectable range.

When connecting to a computer, Windows XP and Vista require third-party drivers to connect to WR320. If WR320 is not set as an audio output device, please check the Bluetooth version of the computer and update it, and then set the audio output device as a speaker.

5.Audio line input

Press the “M” mode switch button to the red indicator light or select “Line Input” in the APP to enter the audio line input mode. Please use the attached audio cable to connect your device and WR320 (AUX IN interface) in this mode, The music of the audio source can be pushed to other Wi-Fi speakers through WR320.

6. Synchronous play and single play mode (only applicable to Wi-Fi connection)

You can select two speakers in the device list for playback settings

Tips: In any interface of the APP, just swipe the page to the left to enter the device list.

WR320 WiFi音乐盒说明书

1. Single play mode

In the single play mode, multiple speakers connected to the same network can each play different songs. The default setting of the speaker is the solo mode.

2. Synchronous playback

In synchronous playback mode, some or all speakers connected to the same network can play the same song. This mode can be used to divide left and right channels between speakers. (Please refer to speaker options)

Long press the icon of a speaker and drag it toward the main speaker to create a speaker group.

Long-press a speaker icon and drag it down to below the upper dotted line on the screen to dismiss the speaker group.

7. Device settings (only applicable to Wi-Fi connection)

Change device settings in the device list

1. Click to view the options that can be set

2. Click “Rename” to change the name of the speaker, select an available name and click “Finish” to confirm the setting, or press “<” to cancel the setting. Click “Customize” to customize the speaker name.

3. Click “Speaker Info” to view the detailed information of the speaker. Select “Restore Factory Settings” to reset the speaker’s Wi-Fi settings.

Tips: Press “L”, “R” or “LR” to switch between left channel, right channel and stereo.

8. Music playback (only applicable to Wi-Fi connection)

In solo mode, multiple speakers can play different songs. In ensemble mode, multiple speakers can play the same song as the main speaker.

The music source can be selected in the APP or on the desktop music software of your mobile phone (supporting protocols AirPlay, Qplay, and DLNA).

Tips: On any interface of the APP, just swipe the page to the right to enter the music source interface.

1. Local music

• Download your favorite songs on the music software that comes with your phone.

• Swipe right to the first page in the APP.

• Click “My Music”, the phone, my playlist, and recently played will be displayed. Click on the mobile phone to see the downloaded favorite songs, just click to play.

• If there is a set up NAS network music server in the local area network, click My Music, you can read the music source in the local area network in the home music sharing.

WR320 WiFi音乐盒说明书

2. Third-party music applications

• Press “+Add Music Service” to change the list of music apps.

• Press a third-party icon to view options or open an app.

Tips: For online music albums, select an album and press WR320 WiFi音乐盒说明书 to save the album and set it as a preset button. The album content can be played directly from the APP device presets and the preset buttons P1 and P2 on the device.
